Recommended for high-pressure hydraulic oil line applications. Easy to route and to install in extremely tight areasAllows for tighter minimum bend radius, increased working pressure and improved impulse cycles than industry standards. Provides greater performance, flexibility, easier routing and plumbing of mobile and stationary hydraulic platforms. Superior flex impulse performance: Tested to 600,000 impulse cycle
Tube:Black, oil-resistant, synthetic rubber (Nitrile - Type C). See Hose Stock Characteristics
Cover:Black, oil, abrasion and weather resistant, synthetic rubber (Modified Nitrile - Type C2), with color coded layline. Also available with unique abrasion resistant MegaTuff® or XtraTuff® cover. See Hose Stock Characteristics.
Reinforcement:Two braids of high-tensile steel wire
Temperature Range:-40°F to +212°F (-40°C to +100°C). For water emulsions see Temperature Limits Table
