Key Features:
● EN/DIN and new SAE rated working pressures
● Flame retardant property of the cover compound, MSHA approved
● Smooth cover FRAS approved (DN5÷12)
● Halogen-Free hose line

Applications& Fluids
● Hydraulics: Low-medium pressure lines, return lines
● Mineral oils, vegetable and rape seed oils, glycol and polyglycol based oils, synthetic ester based oils, oils in aqueous emulsion, water

Continuous service temperature range：
-40°F / +212°F      -40°C / +100°C
Max operating temperature:  +250°F    +121°C
Tuber: oil resistant synthetic rubber
Cover: Environment resistant synthetic rubber
Reinforcement: One high tensile steel braid
Applicable Specs: EN 853 1SN - SAE 100 R1AT - ISO 1436-1 1SN/R1AT
Type Approvals: MSHA, ABS; BV; DNV-GL; FRAS;CU-TR; KRS; NK; LR
