Recommended for extremely high pressure and high impulse hydraulic applications.Exceeds all requirements of ISO 18752 Grade D*, SAE 100R12, EN 856 R12 and ISO 3862 Type R12. *(Sizes 3/8", 1/2" and 5/8" exceed ISO 18752 Grade D performance but does not meet OD requirements). Compatible with biodegradable hydraulic fluids like polyolester, polyglycol and vegetable oil as well as standard petroleum-based fluids. Available in 121' through 200' continuous lengths.
Tube:Black, oil-resistant, synthetic rubber (Nitrile - Type C). See Hose Stock Characteristic
Reinforcement:Four alternating layers of spiraled, high-tensile steel wire.
Cover: Black, oil resistant, synthetic rubber (Polychloroprene - Type A), with color coded layline. Also available with unique abrasion resistant MegaTuff® or XtraTuff® cover. See Hose Stock Characteristics.
Temperature Range: -40°F to +250°F (-40°C to +121°C). For water emulsions see Temperature Limits Table.
