Key Features:
● Validated for high fatigue resistance
● Flame resistance to a wide range of specs.
● Superior abrasion resistance
● High ozone and weather resistance
● Antistatic and antitoxic cover
● BIO biological and mineral oils compatibility

Applications& Fluids
● Hydraulics: heavy duty power lines, hydrostatic transmissions, severe environmental conditions, specific installations with tough abrasion conditions, marine applications, underground and open pit mining
● Mineral oils, vegetable oils and synthetic ester based oils( up to 100°C/+212°F), glycols and polyglycols, mineral oils in aqueous emulsion, water

 Continuous service temperature range：
-40°F / +250°F      -40°C / +121°C
Max operating temperature:  +257°F    +125°C
Tuber: oil resistant synthetic rubber
Cover: Synthetic rubber with high ozone, weather and heat resistance
Reinforcement: Four high tensile steel spirals (DN 6÷25).  six high tensile steel spirals (DN 31÷51).
Applicable Specs:  Exceed EN 856 R12 - SAE 100 R12 - ISO 3862 R12
Type Approvals: ABS; BV; BV(MED); FRAS; CU-TR; LR; MA; MSHA; RINA; B
